The tools we rely on to plan a gallery and its audio chain

Start with paper, not equipment

Before anyone talks about desks or processors, I ask for a single sheet that shows where every sound comes from and where it must end up. Microphones, playback sources, talkback, programme feeds and the return paths for presenters all go on one page, drawn as boxes and arrows. It looks almost too simple, yet it is the tool I rely on most when planning sound and gallery workflow.

The sheet exposes gaps early. A producer will say the show has two presenters and a guest, and the drawing then reveals a phone-in line, a music bed and a clean feed for a remote contributor that nobody had counted. Each of those needs an input, a fader or a route.

I draw it by hand first, then tidy it into a clean version the whole crew can read. The hand sketch is where the arguments happen, and arguments are cheaper at that stage than they are in a rack room on the morning of a recording.

• Every source and every destination on one page
• Return feeds and talkback marked separately
• Remote contributors counted from the first draft

Signal chain notes and gain structure

For each source I write a short chain note: microphone, preamp, any processing, the fader, the bus and the destination. Next to it goes the intended level at each point. Gain structure sounds like a dry subject, but most noisy or distorted audio I am asked to look at comes from a level set too low early on and rescued later, or set too hot and clipped quietly in the middle of the chain.

I use a signal generator and a pair of reliable headphones to walk the chain stage by stage. A test tone at a known level travels from input to output, and I check what arrives at each stop. It takes a quiet half hour and saves a great deal of guessing later.

The notes stay with the studio afterwards, so the next engineer inherits a chain they can follow rather than a tangle they must trust.

• Intended level written beside every stage
• Test tone checked from input to output
• Notes left with the studio for later crews

Desk layouts that suit the people using them

A mixing desk layout is a working arrangement for specific people. I sit down with whoever will mix the show and ask which faders they reach for first. Presenters usually live on the left of the surface, music and playback sit near the centre, and effects or telephone sources go to the edge. Where a console allows layers, I keep the live voices on the layer that is always showing.

Colour labels and clear scribble strips matter more than most budgets admit. A mixer who must read tiny text under pressure will make mistakes, so names go on in plain words, not private abbreviations.

I also leave a few faders spare. Productions change a week before transmission, and an engineer with an empty channel can absorb an extra guest without rebuilding the whole surface.

• Live voices kept on the layer always in view
• Plain-word labels in place of abbreviations
• Spare channels held back for late changes

Gallery workflow and who speaks to whom

The gallery is a room full of people who need to hear each other and the programme at the same moment. I plan communications as carefully as audio: who is on the director's talkback, who hears only the producer, and who can speak to the floor. A single badly arranged intercom can stall a rehearsal quicker than any technical fault.

I use a simple matrix on paper, with roles down one side and channels across the top. Each cell says listen, talk or both. It is checked with the director before any wiring is done, because they know how they actually run a show.

Monitoring gets the same attention. Sound, vision mixing and the producer may all want a different mix in their ears, and agreeing that in advance avoids a lot of quiet frustration during the recording.

• Intercom matrix of roles against channels
• Director consulted before any wiring starts
• Separate monitoring mixes agreed in advance

Checks on the day and in the weeks of autumn

Autumn brings conferences, recorded panels and a run of seasonal broadcasts, and rooms are busy. My method does not change, but I allow more time for line checks because venues are often shared and equipment arrives late. I carry a short written routine: power, clock sync, inputs, outputs, talkback, then a full rehearsal with real speakers rather than a crew member counting to ten.

Radio microphones deserve special care at this time of year, since venues in use all week can have crowded frequencies. I scan the room early and adjust before the guests arrive, not once they are on stage.

Everything is noted as it happens, including what went wrong. That log is plain and honest, and it improves the next plan more than any new piece of equipment would.

• Written routine run in the same order each time
• Radio frequencies scanned before guests arrive
• A log kept of faults as well as successes

Why plain methods hold up

None of this needs special software. A pencil, a tone generator, a good pair of headphones and a habit of writing things down carry most of the work. Fancier tools have their place, and I use them where a console or network system demands it, but they do not replace understanding what each person in the gallery needs.

The test I apply is whether a competent engineer who has never seen the studio could pick up my notes and run a show from them. If the answer is yes, the plan is good enough to hand over.

That is how I approach sound and gallery workflow for the productions we support: clear drawings, measured levels and arrangements agreed with the people who will use them.

The tools behind a reliable gallery are modest ones: a source-to-destination drawing, chain notes with levels, a desk layout built around the mixer, an intercom matrix and a written routine for the day. Each can be repeated and handed on to the next crew. If you are planning audio for a studio or live production, start with the drawing before choosing any equipment, and let it show you what is missing.
